TECE TECElux 400, built-in reservoir 1120 mm, odour extraction,

TECE TECElux 400, built-in reservoir 1120 mm, odour extraction, TECElux toilet installation frame 400, installation height 1120 mm, subsequently height-adjustable, with odor extraction Dry-build concealed cistern for attachment to TECEprofil profile tubes or for installation in metal or wood profile walls and as a front wall or corner installation. For TECElux sen-Touch control glass panel and mounting glass panel. Manually adjustable height of 8 cm, including ceramic-Air odor extraction. Completely pre-assembled built-in reservoir consisting of: Reservoir: safety reservoir made of impact-resistant PP reservoir completely pre-assembled and sealed angle stop valve and reservoir connection pre-assembled reservoir connection with 1/2" external thread 10-liter reservoir capacity; 6-liter preset standard flush volume; 9/7.5/4.5-liter flush volume adjustable at any time; 3-liter partial flush volume with dual flush technology. Any remaining volume can be used directly for cleaning. insulated against condensation according to DIN EN 14055 luminaire group 1 according to DIN 4109 low-noise, hydraulic filling valve Includes insertion shaft for cleaning tablets. For inserting cleaning tablets into the reservoir for fresh rinsing. Mounting frame: self-supporting mounting frame with powder-coated surface depth-adjustable subframe for upper control glass plate and lower mounting glass plate, also manually adjustable in height afterwards two adjustable support feet for a floor construction of 0-200 mm two mounting bolts and nuts M 12 subframe for ceramic toilet bowls with mounting distance 180 mm flexible toilet drain bend DN 90, connection piece material PE-HD (weldable), including transition piece DN 90/100 made of PP toilet connection set DN 90, including shell plugs large shell security suitable for wall construction up to 45 mm Dimensions (h x w x d): 1120 x 500 x 180 mm Low-noise ceramic-Air odour extraction system with durable filter cartridge.
